Static Pass Box Manufacturer

We are leading static Pass Box manufacturer, supplier and exporter in India. Pharmaceutical companies utilise Clean Room Pass boxes to transport materials and to keep classes separate. The location is in a transitional state. Without introducing contaminants into the clean room's air or opening the door, these static pass boxes can be mounted on the wall separating the clean room from the adjacent room. The pass box stops air from moving from one place to another when materials are being transferred. Simple boxes are positioned in a static pass arrangement between two spaces. It also goes by the name "passive pass box" and prevents contaminants from entering the sterile area.

What is Static Pass Box?

Static Pass Box is one of the important equipment of clean room system. It is used to transfer material from one side to other side in a controlled environment to avoid contamination. Its interlocking door system provide extra advantage for material protection. When the one side's door opens then the other side's door remains closed. This pass box is placed between two clean rooms without any air supply. This clean room equipment is also equipped with UV light. Static pass boxes are highly utilized in various sectors such as Laboratories, Pharma companies, Research, Chemical and Food industries.

Function of Static Pass Box

When material is being transferred, the Pass box restricts airflow from one location to another.Simple boxes that are mounted between two places make up a static pass box. It keeps pollutants from entering the sterile region and is also referred to as a passive pass box. Our Static Pass Box device is made of Matt Finish steel and premium components, and it is able to totally remove contaminants from the air. The entering air is filtered by these static pass boxes, which are put in manufacturing facilities to keep the air free of toxins and dust. These static pass boxes have UV light, an hour metre, fluorescent light, a buzzer signal to know the substance is retained within, and an indicating lamp. They function incredibly well in the clean room unit.

Swastik enterprise provide unique static pass box as per the customer specification and requirements.

Cleanroom Static Pass Box Working

  • It has the two doors
  • A glass window is built within the doors to provide visibility of the material being stored for transfer.
  • The cleanroom's door opens first, followed by the other room's door.
  • One door can only be opened at a time since the doors are electronically linked.
  • It stops air from moving directly from one room to another, or vice versa, in a cleanroom.
  • It does away with the need to open the cleanroom door to transfer materials.
  • It assists in completing the material transfer task without lowering the cleanroom's level of cleaning.

    Static Pass Box Application

    Static Pass Box are utilized to transfer materials between two rooms. They does not require ventilation, mainly used to move materials between two equal clean rooms. Transfer between clean and non clean room can not happen. Moreover, They are widely demanded in below given industries.

  • Pharmaceutical industries
  • Hospitals
  • Semiconductor production
  • Chemical research laboratories
  • Food processing industry
  • Electronic industry
  • Microbiology Laboratories

    Features of Static Pass Box

    Our static pass boxes are durable, offer longer services life, easy to operate and deliver minimum noise. We can also provide custom made pass box solutions to customers. Our clean-room equipment are made as per latest industrial standards and available at best price in India. We can also export them to UAE, Africa, USA, Australia and other countries.

  • Easy to clean
  • Easy to integrate
  • Best Performance
  • Advanced air tightness
  • Interlocking
  • Durable
  • Ultra Violet light
  • Minimum maintenance

    Contact the Static Pass Box Manufacturer

    Are you searching for best Static Pass Box manufacturer in India for your clean room requirement? Then contact us as we can help getting best pass box to fulfill your requirements. We manufacture our each of equipment in advanced manufacturing unit and they are made as per latest industrial standard. Moreover, they are highly appreciated among customers for its effective performance. We are also capable to provide custom range of Static and Dynamic Pass Box to suite customer’s specific requirements. Contact us now to get more information about cleanroom equipment and how our offered product can help to fulfill your sterile and safe work requirement.

  • Static Pass Box Specification

    Model SESP150 SESP200 SESP300
    Design type Static / Passive
    Internal Dimension (in mm) 450L x 450W x 450H 610L x 610W x 610H 910L x 910W x 910H
    Outer Dimension (in mm) 570L x 510W x 590H 730L x 670W x 750H 1030L x 970W x 1050H
    MOC Stainless steel 304
    Illumination LED tube light
    Door Two side doors
    Glass window
    SS handles & SS hinges
    Electromagnetic Interlocking system
    Standard Fittings UV light
    Light indicators for door
    SS Handles & SS hinges
    Power supply 220 Volts / 50 Hz
    Optional MOC SS 316 / 316 L
    Flange
    Test certificates
    Mechanical door interlocking
    Door buzzer
    UV light hour meter
